TECHNICAL SPECIFICATIONS CMEX-3 PRO (DC.3000-Pro)

Sensor:
CMOS 1/3 inch

Pixels:
2048 x 1534 pixels, 3.1 MP

Scan mode:
progressive, rolling shutter

Pixel size:
2.2 μm x 2.2 μm

Filter:
RGB

Mount:
C-mount 0.37x

Max fps:
Up to 28 frames per second (2048 x 1534 pixels)
Up to 53 frames per second (1024 x 770 pixels)
(Frame rates have been determined at optimal conditions)

Exposure:
automatic or manual, 0.1 ms to 2000 ms

White Balance:
automatic or manual

Dynamic range:
100 dB

S/N max:
39 dB

Sensitivity V/lux-sec:
1.9

Data interface:
USB 3.0 high speed

Operation:
-10~50°C, 30-80 % humidity

Storage temperature:
-20~60° Celsius

Power supply:
5V over PC USB Port

Housing:
integrated CNC aluminum alloy

Supplied with
0.37x objective with C-mount, USB 3 cable, 30 and 30.5 mm adapters for stereomicroscopes, 76 x 24 mm calibration slide (1mm/100), carton box

Software
ImageFocus Alpha capture and measuring software for Win 10 and higher (32 and 64 bit configurations).
A Mac OS version is available

PC requirements
Compatible with Intel Core 2, 2.8 GHZ or higher, 2GB, USB-3 high speed

Product number:
DC.3000-Pro

___________________________________________________________________________________

TECHNICAL SPECIFICATIONS CMEX-5 PRO (DC.5000-Pro)

Sensor:
CMOS 1/2.5 inch

Pixels:
2560 x 1922 pixels, 5.1 MP

Scan mode:
progressive, rolling shutter

Pixel size:
2.2 μm x 2.2 μm

Filter:
RGB

Mount:
C-mount 0.5x

Max fps:
Up to 16 frames per second (2592×1944 pixels)
Up to 50 frames per second (1296×972 pixels)
Up to 98 frames per second (640×486 pixels)
(Frame rates have been determined at optimal conditions)

Exposure:

automatic or manual

White Balance:
automatic or manual

Dynamic range:
68 dB

S/N max:
39 dB

Sensitivity V/lux-sec:
1.76

Data interface:
USB3.0 high speed

Operation:
-10~50°C, 30-80 % humidity

Storage temperature:
-20~60°Celsius

Power supply:
5V over PC USB Port

Housing:
integrated CNC aluminum alloy

Supplied with
0.5x objective with C-mount, USB 3 cable, 30 and 30.5mm adapters for stereomicroscopes, 76x24mm calibration slide (1mm/100), carton box

Software
ImageFocus Alpha capture and measuring software for Win 10 and higher (32 and 64 bit configurations).
A Mac OS version is available

PC requirements
Compatible with Intel Core 2, 2.8 GHZ or higher, 2GB, USB-3 high speed

Product number:
DC.5000-Pro

___________________________________________________________________________________

TECHNICAL SPECIFICATIONS CMEX-10 PRO (DC.10000-Pro)

Sensor:
CMOS 1/2.3 inch

Pixels:
3584 x 2746 pixels, 10.0 MP

Scan mode:
Progressive, rolling shutter

Pixel size:
1.67 μm x 1.67 μm

Filter:
RGB

Mount:
C-mount 0.5x

Max fps:
Up to 8 frames per second (3584 x 2746 pixels)
Up to 25 frames per second (1792 x 1372 pixels)
(Frame rates have been determined at optimal conditions)

Exposure:
automatic or manual

White balance:
automatic/manual

Dynamic range:
63.5 db

S/N max:
35.5 db

Sensitivity V/lux-sec:
0.31

Data interface:
USB 3.0 high speed 80 Mb/s

Operation:
0 – 50°C, 30-80 % humidity

Storage temperature:
-20 to 60° Celsius

Power supply:
5V over PC USB port

Housing:
integrated CNC aluminum alloy

Supplied with
0.5x objective with C-mount, USB 3 cable, 30 and 30.5 mm adapters for stereomicroscopes, 76 x 24 mm calibration slide (1mm/100), carton box

Software
ImageFocus Alpha capture and measuring software for Win 10 and higher (32 and 64 bit configurations).
A Mac OS version is available

PC requirements
Compatible with Intel Core 2, 2.8 GHZ or higher, 2GB, USB-3 high speed

Product number:
DC.10000-Pro

___________________________________________________________________________________

 TECHNICAL SPECIFICATIONS CMEX-20 PRO (DC.20000-Pro)

Sensor:
CMOS 1/1.8inch

Pixels: 5120 x 3840 pixels, 20.0 MP

Scan mode:
progressive, rolling shutter

Pixel size:
1.4 μm x 1.4 μm

Filter:
RGB

Mount:
C-mount 0.75x

Max fps:
Up to 20 frames per second (5120 x 3840 pixels)
Up to 45 frames per second (2560 x 1920 pixels)
(Frame rates have been determined at optimal conditions)

Exposure:
automatic or manual

White balance:
automatic/manual

Dynamic range:
39 db

S/N max:
60 db

Sensitivity V/lux-sec:
8.4 ke−/lux.sec

Data interface:
USB 3.0 high speed 80 Mb/s

Operation:
0 – 50°C, 30-80 % humidity

Storage temperature:
-20 to 60°Celsius

Power supply:
5V over PC USB port

Housing:
integrated CNC aluminum alloy

Supplied with:
0.75x objective with C-mount, USB 3 cable, 30 and 30.5 mm adapters for stereomicroscopes, 76 x 24 mm calibration slide (1mm/100), carton box

Software:
ImageFocus Alpha capture and measuring software for Win 10 and higher (32 and 64 bit configurations).
A Mac OS version is available

PC requirements:
Compatible with Intel Core 2, 2.8 GHZ or higher, 2GB, USB-3 high speed

Product number:
DC.20000-Pro
